| Rated air volume | 80003/h |
| Pipe diameter of inlet | Φ400mm |
| Oil drain caliber | DN32+Automatic drain pump |
| Motor power | External fan 15KW |
| Voltage | 3*380V/20-50HZ(Variable Frequency) |
| Size of equipment | 2850(H)*2080(L)*1100(W) |
| Filter element size | 1000*925*700(Primary Stage)1000*925*595(Secondary Stage)1000*925*292(Tertiary Stage) |
| Installation method | Place on the side of the machine tool or on the side of the wall, connected by pipes. |
| Applicable working condition | Suitable for light oil mist (smoke) 60-100mg and below, medium heavy-duty air volume system |
