| Rated air volume | 4000m3/h |
| Pipe diameter of inlet | Φ325mm |
| Oil drain caliber | DN32+Automatic drain pump |
| Motor power | 7.5KW |
| Voltage | 3*380V/20-50HZ(Variable Frequency) |
| Size of equipment | 3321(H)*1095(L)*1100(W) |
| Filter element size | 1000*925*700(Primary Stage)1000*925*595(Secondary Stage)1000*925*292(Tertiary Stage) |
| Installation method | Place on the side of the machine tool or on the side of the wall, connected by pipes. |
| Applicable working condition | Suitable for light oil mist (smoke) 40-70 mg and below, medium heawy-duty air volume system. |
